RF Device Data

Freescale Semiconductor

MRF8P9040NR1 MRF8P9040GNR1 MRF8P9040NBR1

Table 1. Maximum Ratings

Rating

Symbol

Value

Unit

Drain--Source Voltage

VDSS

--0.5, +70

Vdc

Gate--Source Voltage

VGS

--6.0, +10

Vdc

Operating Voltage

VDD

32, +0

Vdc

Storage Temperature Range

Tstg

--65 to +150

°C

Case Operating Temperature

TC

150

°C

Operating Junction Temperature

(1,2)

TJ

225

°C

Table 2. Thermal Characteristics

Characteristic

Symbol

Value

(2,3)

Unit

Thermal Resistance, Junction to Case

(4)

Case Temperature 77°C, 4.0 W CW, 28 Vdc, IDQ

= 320 mA, 960 MHz

Case Temperature 81°C, 40 W CW, 28 Vdc, IDQ

= 320 mA, 960 MHz

RθJC

1.5

1.3

°C/W

Table 3. ESD Protection Characteristics

Test Methodology

Class

Human Body Model (per JESD22--A114)

1B (Minimum)

Machine Model (per EIA/JESD22--A115)

A (Minimum)

Charge Device Model (per JESD22--C101)

III (Minimum)

Table 4. Moisture Sensitivity Level

Test Methodology

Rating

Package Peak Temperature

Unit

Per JESD22--A113, IPC/JEDEC J--STD--020

3

260

°C

Table 5. Electrical Characteristics

(TA

=25°C unless otherwise noted)

Characteristic

Symbol

Min

Typ

Max

Unit

Off Characteristics

(4)

Zero Gate Voltage Drain Leakage Current

(VDS

=70Vdc,VGS

=0Vdc)

IDSS

?

?

10

μAdc

Zero Gate Voltage Drain Leakage Current

(VDS

=28Vdc,VGS

=0Vdc)

IDSS

?

?

1

μAdc

Gate--Source Leakage Current

(VGS

=5Vdc,VDS

=0Vdc)

IGSS

?

?

1

μAdc

On Characteristics

(4)

Gate Threshold Voltage

(VDS

=10Vdc,ID

= 170

μAdc)

VGS(th)

1.5

2.3

3.0

Vdc

Gate Quiescent Voltage

(VDD

=28Vdc,ID

= 320 mAdc, Measured in Functional Test)

VGS(Q)

2.3

3.1

3.8

Vdc

Drain--Source On--Voltage

(VGS

=10Vdc,ID

=0.55Adc)

VDS(on)

0.1

0.17

0.3

Vdc

1. Continuous use at maximum temperature will affect MTTF.

2. MTTF calculator available at http://www.freescale.com/rf. Select Software & Tools/Development Tools/Calculators to access MTTF

calculators by product.

3. Refer to AN1955,

Thermal Measurement Methodology of RF Power Amplifiers.

Go to http://www.freescale.com/rf.

Select Documentation/Application Notes -- AN1955.

4. Measurement made with device in single--ended configuration. (See Figure 3, Possible Circuit Topologies)

(continued)
